Description
Cadre
Carbon Main Frame / Alloy SST-CST-Link
Virtual 4 link kinematic VLK
29×2.6 / Boost 148x12mm UDH
160mm travel / Bosch Gen4 / Integr. removable Battery
1.8″ Headtube, Central Kickstand Mount
Integr. Cable
Débattement
Front: 160mm / Rear: 160mm
Fourche
FOX 38 Perf. Elite Air / eMTB+ / FIT4
3-Modes with low Speed adj. / QR Axle 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout / 160mm travel
Amortisseur arrière
FOX NUDE T eRIDE EVOL / Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
custom large air volume / DPS / Reb. Adj.
Travel 160-115-Lockout / 205X60mm
Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes
Moteur
Bosch Performance CX
EU: 25kmh / INT: 20mph
Batterie
PowerTube 750Wh
Ecran
Bosch LED Remote & Kiox 300
Chargeur
4A Charger
Dérailleur arrière
Shimano XT / 12 Speed
Manettes de dérailleur
Shimano SL-M8100
Pédalier
FSA CK-745 165mm / 34T
Guide-chaîne
e*thirteen / e*spec Slider
Plateau
FSA WB604 / 34T / DM / Steel
Chaîne
Shimano CN-M8100
Cassette
Shimano CS-M8100 / 10-51 T
Freins
Shimano XT / BR-M8120 4 Piston
Disque de frein
Front: RT-MT800 CL 203mm / Rear: RT-EM800 CL 203mm
Cintre
Syncros Hixon 1.5 / Alloy 7050D.B.
12mm rise / 9° / 780mm
Syncros Pro lock-on grips
Potence
Syncros AM1.5 / 7050 Alloy
31.8mm / 4° / 1 1/8″
Tige de selle
FOX Transfer Dropper Post
31.6mm / S size 125mm / M & L size 150mm / XL size 175mm
Selle
Syncros Tofino 1.5 Regular
Titanium rails
Jeu de direction
Acros / 1.8″
ZS66 OD74 / integr. Cable
Moyeu avant
Formula CL-811 / 15x110mm
Moyeau arrière
Formula ECT-1481 / Boost 148x12mm
Rayons
Stainless Black
Jante
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready
Pneu avant
Maxxis Dissector 29×2.6″
120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra
Pneu arrière
Maxxis Dissector 29×2.6″
120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra
Eclairage
Bosch Light Cable pre-installed F&R
Extras
Syncros Trail 2 fender 36/38
Syncros eRIDE integrated light fender
Poids en Kg (App.)
24.60
Poids en Lbs (App.)
54.23
Poids global
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
