Description
Cadre
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fourche
FOX 36 Float Performance Elite Air FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout
160mm travel
Amortisseur arrière
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 150-100-Lockout / T185X55mm
Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Dérailleur arrière
SRAM GX Eagle AXS 12 Speed
Wireless Electronic Shift System
Manettes de dérailleur
SRAM GX Eagle AXS Rocker Controller
Pédalier
SRAM GX Eagle DUB
55mm CL / 32T
Guide-chaîne
SCOTT custom
Boitier de pédalier
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chaîne
SRAM CN GX Eagle
Cassette
SRAM XG1275 / 10-52 T
Freins
Shimano XT M8120 4 Piston Disc
Disque de frein
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
Cintre
Syncros Hixon iC Carbon
Size S & M 15mm rise / Size L & XL 25mm rise
back sweep 8° / 780mm
Syncros Endurance lock-on grips
Tige de selle
Syncros Duncan Dropper Post 1.5
31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
Selle
Syncros Tofino 1.5 Regular
Titanium rails
Jeu de direction
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Paire de roues
Syncros Revelstoke 1.5 6 Bolt
F: 15x110mm, R: 12x148mm
30mm Tubeless ready rim 28H / XD Driver
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
Pneu avant
Maxxis Dissector / 2.6″ / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
Pneu arrière
Maxxis Dissector / 2.6″ / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
Extras
SRAM AXS Powerpack
Syncros Fork Fender
Poids en Kg (App.)
14.1 (Tubeless setup)
Poids en Lbs (App.)
31.09 (Tubeless setup)
